洛氏标尺(Rockwell Scales) | HRA, HRB, HRC, HRD, HRE, HRF,HRG,HRH,HRK |
初试验力(Initial Testing Force) | 10Kg(98.07N) |
试验力(All Testing Force) | 60Kg (588N), 100Kg (980N), 150Kg (1471N) |
硬度读取 (Indication of Hardness Value) | 表盘式(Dial ) |
试件*大高度 Max. Height of Specimen | 400mm |
仪器尺寸(Overall Dimension) | 520X220X920MM (长X宽X高, LXWXH) |
仪器重量(Net Weight) | 80 Kg |
执行标准 (Carried Standard) | GB/T230.2 **标准、JJG112检定规程 GB/T230.2 Chinese Standard and JJG112 Inspection Rule |
标准配件、附件 (Standard Accessories) | 金刚石洛氏压头,直径1.5875mm硬质合金球压头,大平试台、中平试台、V型试台,硬度块 Diamond Rockwell Indenter, Diameter 1.5875mm Hard Alloy Steel Ball Indenter, Large Testing Table , Medium Testing Table and V-shaped Testing Table, HRC and HRB Hardness Blocks |
